Practice questions Sub: EDG 312311
Practice questions Sub: EDG 312311 Projections of Solids a) A hexagonal prism edge of base 25 mm and axis 60 mm long rests on H.P. on an edge of base with that edge perpendicular to V.P. and axis inclined 45° to H.P. and Parallel to V.P. Draw: i) F.V. ii) T.V. b) A pentagonal pyramid side of base 30 mm and axis length 65 mm is kept on the H.P. on a corner of its base such that axis makes an angle of 30° to the H.P. and parallel to the V.P. Draw its projections. c) A square pyramid, side of base 35 mm, axis length 65 mm lying on the HP with all edges of bases are equally inclined to V.P .Its Axis inclined at 45 ⁰ to HP and parallel to V.P. Draw its projectio...
